Fixed port

6x10/100Base-T

Power interface

AC100-240V   triangle interface

LED Indicators

P , Active

Cable Type &   Transmission Distance

Twisted-pair

0-100m/ 250m

Network Topology

Ring topology

Not Support

Star topology

Support

Bus topology

Support

Tree Topology

Support

Electrical Specifications

Input voltage

AC 100-240V   50/60Hz

Total Power consumption

<72W(PoE)

Main board power

<2W

PoE

PoE protocol

802.3AF，802.3AT

Pin Assignment

12+ /36-

Pin port

1-4

Dialing switch Instruction

1 extend

250m long distance   transmission

2 standard

Standard mode

3 port isolation

1-4 port port   isolation

Layer 2 Switching

Switching   capacity

1.2G

Packet forwarding   rate

0.89Mpps

MAC address   table

2K

Buffer

768k bit

Jumbo frame

2K bytes

Forwarding delay

<5us

MDX/MIDX

Support

Storm control

Support

Environment

Operating   temperature

-10℃~+50℃

Storage   temperature

-40℃~+70℃

Relative   humidity

5%~90%   (non-condensing)

Thermal methods

Fanless   design, natural heat dissipation

MTBF

100,000 hours

EMC & Ingress Protection

Surge protection   of Power

Common mode 6KV, differential-mode 4KV

Surge protection   of Ethernet port

Common mode 6KV, differential-mode 4KV

ESD

Contact 8KV, Air   15KV

Free fall

0.5m

Mechanical Dimensions

Product size

190*140*44mm（LxWxH）

Installation   Method

Desktop

Weight

0.6KG

Packing List

Packing list

Device,   Inspection Certificate, User manual, Power cord
