FEATURES AND HIGHLIGHTS：
Specifications：
|
Fix Ports |
|
|
Fixed port |
8x10/100/1000 Base-T |
|
Power interface |
DC connector |
|
LED Indicator |
|
|
PER |
Power indicator |
|
Link/Act |
Link status indicator |
|
Cable Type & Transmission Distance |
|
|
Twisted-pair |
0-100m（CAT5e,CAT6） |
|
Network Topology |
|
|
Ring topology |
Not Support |
|
Star topology |
Support |
|
Bus topology |
Support |
|
Tree Topology |
Support |
|
Electrical Specifications |
|
|
Input voltage |
DC5V |
|
Total Power consumption |
≤5W |
|
Layer 2 Switching |
|
|
Switching capacity |
16G |
|
Packet forwarding rate |
11.9Mpps |
|
MAC address table |
4K |
|
Buffer |
2M bytes |
|
Forwarding delay |
<10us |
|
MDX/MIDX |
Support |
|
Jumbo frame |
10K bytes |
|
Environment |
|
|
Operating temperature |
-10℃~+50℃ |
|
Storage temperature |
-40℃~+70℃ |
|
Relative humidity |
10%~90% (non-condensing) |
|
Thermal methods |
Fanless design, natural heat dissipation |
|
MTBF |
100,000 hours |
|
EMC & Ingress Protection |
|
|
Surge protection for Ethernet port |
Common mode 6KV; differential mode: 4KV |
|
Surge protection for power |
Common mode 6KV; differential mode: 4KV |
|
DIP |
IEC 61000-4-11 Level3 （10V） |
|
ESD |
IEC 61000-4-2 Level 4 （8K/15K） |
|
Free fall |
0.5m |
|
Mechanical Dimensions |
|
|
Product size |
175*73*28mm(L*W*H) |
|
Installation Method |
Desktop/ Wall mounted |
|
Weight |
0.35KG |
|
Packing List |
|
|
Packing list |
Device, Inspection Certificate, User manual, AC Power cord |
Dimensions：
