FEATURES AND HIGHLIGHTS：
Specifications：
|
Provider Mode Ports |
|
|
Port type and quantity: |
8 x 10/100/1000 Base-T+ 2x1000Base-X |
|
Management Port |
Support console |
|
Power Supply |
100-240V/AC |
|
LED Indicators |
PWR, Link/ACT LED |
|
Network Size – length of cable |
|
|
Twisted pair (TP): |
0-100m（CAT5e,CAT6） |
|
Single mode Fiber (SMF): |
20/40/60/80/100KM |
|
Multimode Fober (MMF): |
550m |
|
Network Topology |
|
|
Ring topology |
Support |
|
Star topology |
Support |
|
Bus topology |
Support |
|
Tree Topology |
Support |
|
Hybrid topology |
Support |
|
Electrical Specifications |
|
|
Input voltage |
AC 100-240V 50/60Hz |
|
Power consumption: |
＜120W |
|
Main board power |
＜10W |
|
PoE Support |
|
|
PoE port |
1-8 |
|
PoE Protocol |
802.3af，802.3at |
|
Pin Assignment |
1,2+; 3,6- |
|
PoE Management |
Support |
|
Layer 2 Switching |
|
|
Switching capacity |
20Gbps |
|
Packet forwarding rate |
14.88Mpps |
|
MAC address table |
8K |
|
Buffer |
4.1M |
|
Forwarding delay |
<10us |
|
MDX/MIDX |
Support |
|
VLAN |
256 |
|
GVRP VLAN |
Support |
|
Protocol VLAN |
Support |
|
Voice VLAN |
Support |
|
Surveillance VLAN |
Support |
|
MAC VLAN |
Support |
|
Ethert channel/ 802 .3ad |
Support |
|
LACP |
Support |
|
Interface Speed |
Support |
|
Duplex Mode |
Support |
|
Flow Control |
Support |
|
Jumbo frame |
Support |
|
DHCP Client |
Support |
|
SNTP Client |
Support |
|
Port Statistics |
Support |
|
Protected Ports |
Support |
|
EEE |
Support |
|
Ethernet Ring Protection Switching |
Support |
|
LLDP |
Support |
|
LLDP 802.1 TLV |
Support |
|
MSTP / RSTP / STP |
Support |
|
STP BPDU Filter |
Support |
|
STP BPDU guard |
Support |
|
STP Port Fast |
Support |
|
IGMP Snooping |
Support |
|
MLD Snooping |
Support |
|
MVR |
Support |
|
Layer 3 Route |
|
|
IPV4 management |
Support |
|
IPV6 management |
Support |
|
Static Routes IPv4 |
32 |
|
Static Routes IPv6 |
32 |
|
ARP |
Support |
|
Loopback Interface |
Support |
|
DHCP Server |
Support |
|
DNS Server |
Support |
|
DNS Client |
Support |
|
Convergence |
|
|
ACL |
Support MAC Standard/Extended ACL Support IPV4 Standard/Extended ACL Support IPV6 Standard/Extended ACL |
|
QoS |
Support QoS Remarking Support Port Trust Support Port bandwidth Support egress queuing bandwidth Support SP，WRR Support COS，DSCP，IP Priority |
|
Management |
|
|
User Management |
Support |
|
System Log |
Support |
|
Upgrade Firmware |
Support |
|
Configuration File Download/Upload |
Support |
|
SNMP |
Support SNMP V1/V2/V3 |
|
WEB |
Support |
|
Console |
Support |
|
CLI |
Support |
|
Telnet/SSH |
Support |
|
RMON |
Support |
|
Security |
|
|
management channel configuration |
Support |
|
AAA |
Support |
|
802.1X |
Support |
|
MAC-Based |
Support |
|
WEB-Based |
Support |
|
DoS |
Support |
|
ARP |
Support |
|
DHCP Snooping |
Support |
|
IP Source Guard |
Support |
|
Port Security |
Support |
|
Protected Ports |
Support |
|
Storm control |
Support |
|
Equipment diagnosis |
|
|
Console log |
Support |
|
RMA log |
Support |
|
Flash log |
Support |
|
Port mirroring |
Support 1:1 or 1:M |
|
Ping |
Support |
|
Traceroute |
Support |
|
Copper port test |
Support |
|
SFP transceiver information |
Support |
|
UDLD protocol |
Support |
|
Environment |
|
|
Operate temperature |
-10ºC to 50ºC |
|
Storage temperature |
-40ºC to 85ºC |
|
Relative humidity |
10% to 90% RH |
|
Heat Dissipation Method |
Fanless, natural cooling |
|
MTBF |
100,000H |
|
Mechanical Dimensions |
|
|
Dimensions (WxHxD): |
220*161*44mm |
|
Mounting |
Desktop |
|
Weight |
1kg |
|
EMC & INGRESS PROTECTION |
|
|
Surge protection of Power |
Common mode 6KV; differential mode: 4KV |
|
Surge protection of Ethernet |
Common mode 6KV; differential mode: 4KV |
|
Electrostatic discharge (ESD) |
8 kV contact discharge，15 kV air discharge |
|
Free fall |
0.5m |
|
Accessories |
|
|
Accessories |
Device, Power cord, User manual |
Dimensions：
